Melco Music Library

Many music lovers currently using entry level/computer based digital file music systems want to experience better quality sound yet there has been a gap in the market place for an easy to use Hi-Fi audio component. The Melco design team has addressed this need with a range of high resolution music server products that do not require specialist knowledge to install, configure or use. These provide very high quality high resolution streaming to a network player and/or USB DAC, significantly exceeding the performance possible from an optimally configured Laptop or PC based server.


What you can do with a Melco


Store and play high resolution digital music files

Rip and play CDs by connecting a USB optical drive mechanism

Play songs using tablet or smart phone control with easy menu tree

Back-up to or play from external storage

Expand with additional external storage

Display song title playing, sampling rate, storage used

One click firmware upgrades

Easily integrate with existing systems on compability list

Easily set-up with front panel buttons and display prompts

Host 2 devices directly: Network Player and USB DAC

Automatically searches multiple on-line databases for album art

Songkong App available to tidy up iTunes libraries with duplicate tracks and find missing album art



Melco versus a Laptop, PC based server or Mac Mini

Few audiophiles have the specialist knowledge needed to build a system from scratch and there are limits to what can be done with a general purpose PC/Laptop at the software and hardware level. Computers connected to the Internet implement an Internet Protocol suite operating across several ports so multiple tasks - read/send emails, opening several browser windows etc. - can all be done at the same time. The only task a dedicated audio product needs to do is to stream audio data without compromise. General purpose computer operating systems control the priority of the ongoing multitude of tasks required by the CPUs, and because audio processing is never the highest priority, it is constantly interrupted with other higher priority tasks resulting in data corruptions and timing errors creating jitter in the audio samples. Internal USB data transfer may not be bit perfect in PCs unless the drivers are well designed and robust. Writing to and reading from disk drives is optimized for IT based data, not audio streaming. And the whole computer environment is noisy from the closely packed circuits and switched mode power supplies.

For networking, there is also the ability and quality of the router and switch to consider. Those provided by Internet Service Providers or sold in stores are designed for multi-functionality and speed rather than being solely concerned with streaming audio.


The Technology Melco Uses for Better Sound

Separate Input and Output Ethernet ports and an internally managed switch

Conventional network players that plug into a router directly receive all the network traffic and noise from the router. The Melco sits between the router and the player. Inside the Melco N1A and N1ZH, a powerful dedicated processor manages the data packets (re-order, deal with missing or duplicated packets etc.),creates the audio samples, and strips away all unwanted network traffic (such as TV DLNA, gaming, shopping) so only pure audio and control data is sent to the player via the dedicated player Ethernet port. In direct mode the Melco is completely off the network and provides the player with an IP addreses.

Optically isolated Ethernet ports

No noise is passed on to the player or therefore the rest of the audio system.

Twin internal low-noise power supplies

The Melco N1A and N1ZH use a sophisticated fully grounded internal Power Supply Units; one for internal, and one for external comms. In the N1Z these are medical grade. The twin supplies are far superior to wall warts and the internal supplies used in most other streamers. Furthermore most wall warts use basic switched mode power supplies, and unlike the high quality ones used audio amplifiers, these generate their own noise and contaminate the mains supply feeding the other components in the Hi-Fi system.

Separate regulators for the main processor elements and data clock

This ensures long term stable performance. This level of sophistication is not even considered in plastic NAS drives

True ground reference using 3-wire IEC connector and metal casework

Laptops and NAS drives that use a wall wart or internal batteries have a floating ground. Without a physical ground, circulating ground currents within the USB environment add noise to the system. Wall warts and 2-wire inline supplies have no grounding for interference rejection.

Internal architecture designed for low jitter data

The focus is on precision bit perfect data rather than speed. The Melco N1A and N1ZH use a USB-like internal bus architecture that always keeps the data under rigorous clock control, something which is never the case in the computer environment. With this proprietary bus architecture in place, incorporating backup and expansion USB 3 ports, plus two additional USB ports, is now straight forward. Functionality is controlled via front panel controls and the display prompts making it easy to backup data or transfer files from USB thumb drives (that can also be directly read.) With Melco, data is precision clocked all the way to the USB audio connectors which become true high fidelity interfaces.

Custom hard drive control electronics

Melco writes to and reads from internal hard drives in a different way than implemented in standard computers. The audio-grade duty internal disc drives are run at a lower speed than conventional PC drives and there is no noisy fan in the unit. Standard solid state drives SSDs)sound worse because background life optimisation algorithms (needed to prolong life on SSDs that have finite number of times memory locations can be written to and read from) intrude into music streaming

Optimized Server

Melco uses specially optimised version of Twonky. Memory allocation management in standard UPnP servers is not designed for high quality audio especially with very large audio files.

Higher bandwidth cables

Melco is supported by a range of precision engineered data cables to reduce rise time and prevent cable induced jitter.

In essence PC or MAC based systems will play a tune but are prevented from true high resolution audio because they are crippled from the start by inferior power supplies generating noise, and bad data timing from poor pulse edges and reflections on the data bus. They have no concept of low jitter because for regular data processing it is irrelevant. Melco replaces IT industry NAS based streaming systems and replaces PC and music player software for direct USB connection to a DAC.

Overall by using dedicated hardware design and customized data management, the Melco N1A and N1ZH, minimize the errors, noise, and jitter that degrades sound performance, while the dedicated server software and simple user interface make the product easy to use. The preinstalled media server arranges your music by artist/album/folder etc. and you can label and set up your own folder hierarchy.

Integrating Melco into Your System

The Melco N1A and N1ZH can be used in three ways:

Using an Ethernet cable connect the Melco's LAN input port to a free port on your Wireless router. Using a USB cable connect one of the Melco's USB outputs to a USB DAC. Installing any general Control Point App (Lumin, Kinsky and many others)on an Ipad/Iphone/Android device enables music selection. A good USB cable should be used. The Melco will automatically handle the different sample rate ability of the DAC and you can configure to convert DSD data to PCM for DACs which do not handle DSD data.

For network players, such as Primare's NP30, connect the Melco's LAN input port to a free port on your Wireless router and connect another Ethernet cable from the player port of the Melco to the Ethernet input on the player. The network player's wireless iPad/Android App will see the Melco on the network as a music server. These Apps usually include Internet radio and sometimes also control input and volume functions for the system. A good short Ethernet cable (CAT 7 or CAT 8) between the Melco and the player will improve sound quality.

Finally the Melco can be used off the network entirely (no internet radio), and without control app, by connecting to a Network Player with internal volume control and remote control such as Chord's DSX1000. Using a CAT 7 or CAT 8 cable results in a fantastic sound. Using the Network Player's remote is just like operating a CD player and utterly reliable free from network glitches or app freezes. In this mode, adding new music to the Melco can be done simply by transferring from plug-in USB drives.

No router in the room where your HiFi is located?. No Problem.

About Melco

Melco stands for Maki Engineering Laboratory Company and is a family business based in Japan where the product is manufactured. Makoto Maki, the founder, is an enthusiastic audiophile and had previously released a very high end turntable in the UK in 1980. Melco developed into the largest computer peripherals manufacturer in Japan, currently with fourteen global subsidiaries the largest of which is Buffalo Inc. Buffalo's USA division is located in Austin Texas. The Melco music library products are the result of a two year collaborative effort and included many highly respected audio industry experts.

The Melco N1A and Melco N1ZH come with a two-year non-transferable limited warranty.


Melco N1A music library

Melco N1A 4TB Music Library

  • Versatile Plug-n-Play audiophile music library/server with OLED display
  • Use ethernet connection to network player/streamer or USB cable to a DAC, or both
  • Dedicated LAN port for Network Audio Player to purify network traffic and overcome router limitations
  • Low noise light-piped LED Ethernet port indicators
  • Audio grade power supply and ultra low jitter data clock
  • Pre-installed media server - no configuration required
  • Ability to rip CDs and direct download music without PC from partnering vendors
  • Can play music from open shares on network, plugged in USB drives, in addition to music stored on the Melco
  • Supports PCM up to 384 kHz/32 bit and up to 5.6 MHz double DSD
  • Automatically adjusts sample rate to match capability of DAC and converts DSD to PCM for non-DSD DACs
  • Firmware can be updated by USB stick or directly on-line
  • No fan, internal drives are barely audible
  • Dimensions: 17.2" x 2.8" x 13.9" (WHD); Weight: 15.5 lbs
  • List Price: $1,999; black or silver finish - Last one

Melco N1A/2 4TB Music Library

  • New Mk2 version of popular N1A with sonic improvements particularly for DAC users
  • Anti-vibration craddles for new select dual 2TB HDD drives, audio-grade capacitor bank for 60 watt power supply, Neutrik USB 2 port for DAC, high current 3-pole true ground IEC mains connector with built-in noise filter
  • Ultra low jitter data clock and micro miniature high performance network pulse transformers to minimize digital signal distortions
  • Dedicated LAN port for Network Audio Player to purify network traffic and overcome router limitations
  • Use ethernet connection to network player/streamer or USB cable to a DAC, or both
  • Pre-installed media server - no configuration required
  • Ability to rip CDs and direct download music without PC from partnering vendors
  • Can play music from open shares on network, plugged in USB drives, in addition to music stored on the Melco
  • Supports PCM up to 384 kHz/32 bit and up to 5.6 MHz double DSD
  • Firmware can be updated by USB stick or directly on-line
  • Dimensions: 17.2" x 2.4" x 13.9" (WHD); Weight: 15.2 lbs
  • List Price: $2,499; black or silver finish

Melco N1ZH 6TB Music Library

  • Enhanced model with floating drive mechanisms, very sophisticated power supplies, and thick aluminum casing
  • Dedicated LAN port for Network Audio Player to purify network traffic and overcome router limitations
  • Light piped Ethernet ports for complete electrical isolation
  • Dual medical grade power supplies and high-quality capacitor bank
  • Pre-installed media server - no configuration required
  • Ability to rip CDs and direct download music without PC from partnering vendors
  • Can play music from open shares on network, plugged in USB drives, in addition to music stored on the Melco
  • Supports PCM up to 384 kHz/32 bit and up to 5.6 MHz double DSD
  • Automatically adjusts sample rate to match capability of DAC and converts DSD to PCM for non-DSD DACs
  • Firmware can be updated by USB stick or directly on-line
  • No fan, internal drives are barely audible
  • Dimensions: 13.8" x 2.9" x 14.6" (WHD); Weight: 18.7 lbs
  • List Price: $4,499; black or silver finish - Last one

Melco N1ZH/2 6TB Music Library

  • Flagship model of the new Mk2 series
  • Twin low noise SFF hard drives mounted on massive non-magnetic foundation
  • New audio-grade film capacitor banks for twin medical-grade power supplies
  • New dedicated Neutrik USB 2 port for DAC
  • Three USB 3 ports for easy back-up, expansion, CD ripping from external disk drives, and import from USB flash/HDD drives
  • Dedicated LAN port for Network Audio Player to purify network traffic and overcome router limitations
  • Light piped Ethernet ports for complete electrical isolation
  • Pre-installed media server - no configuration required
  • Ability to rip CDs and direct download music without PC from partnering vendors
  • Can play music from open shares on network, plugged in USB drives, in addition to music stored on the Melco
  • Supports PCM up to 384 kHz/32 bit and up to 5.6 MHz double DSD
  • Firmware can be updated by USB stick or directly on-line
  • Dimensions: 13.8" x 3.0" x 14.6" (WHD); Weight: 17.9 lbs
  • List Price: $5,499 ; black or silver finish
